Aeon Mira 7 laser CO2

Show Price
  • - itemNo. 1581
  • - Features.
    • Size: 45 x 70 cm
    • Laser Power: 60W
    • Working Area: 450X700(mm)
    • Electric Up and Down table: 150mm
    • Auto-Focus Red light combiner location
Category: Aeon
Product Code: 1581

  • WIFI, Ethernet and USB2.0
  • True color TFT screen
  • Preview of drawings saved in memory
  • Resume engraving after power-down and work-hour preview
  • Locating Precision: <0.01mm
  • Min Shaping Character:2*2mm,letter:1*1mm
  • Maximum Cutting Depth: 8mm for acrylic, plywood, 3mm for harder material
  • Maximum Engraving Depth: 2-3mm for acrylic, plywood, 12mm for harder material





  • Drive Type: Micro Stepping Motor
  • Machine Size: 1100*845*480 (mm)
  • Packing Dimensions: 1220*970*700 (mm
  • Voltage: 220V 50HZ/60HZ
  • N.W.: 135KG
  • G.W.:158KG



WARRANTY: One year parts and labor on all manufacturer's defect excluding laser tube, lens, mirrors, and damage due to electrical surges.
